Macintosh
Phaser® 7760 Color Laser Printer
3-16
Enabling and Using TCP/IP for Mac OS 9.x
This section provides installation and troubleshooting steps for Macintosh OS 9.x.
Setting Up the Macintosh Ethernet Port for TCP/IP
To set up your Macintosh for TCP/IP:
1. On the control panel, select TCP/IP, and then select Ethernet.
2. Specify how you will obtain the IP address from the TCP/IP tab:
■ Manually: Specify the IP address, Subnet Mask, Router Address, and Name Server
Address in the dialog box.
■ Using DHCP Server: Automatically finds the IP address.
3. Close the dialog box.
See also:
Knowledge Base at www.xerox.com/office/7760support
