Xerox VersaLink C405/N

Getting Started
Xerox
®
VersaLink
®
C405 Color Multifunction Printer 25
User Guide
Rear View
6
8
7
9
10
11
12
1
2
3
4
5
1. Duplex Unit
2. Transfer Roller
3. Fuser
4. Power Connector
5. Rear Door
6. Left Side Cover
7. Phone Line Connector
8. Fax Line Connector
9. Wireless Network Adapter Port Cover
10. USB Port, Type B
11. Ethernet Port
12. FDI Connector
