Xerox VersaLink C7130 User Documentation

13. Touch Next.
14. Touch the option required.
• Personal (My Home Screen Only): Use this option to display the 1-Touch App on your Home
screen only when you are logged in to your user account.
• Public (Public Home Screen): Use this option to make the 1-Touch App accessible to all users.
15. Touch Done.
Deleting or Hiding a 1-Touch App
To delete or hide a 1-Touch App from the Home screen:
1. At the printer control panel, press the Home button.
2. If deleting or hiding a Personal 1-Touch App, touch Login, then enter a valid login name and
password.
3. Touch Customize.
4. For the required 1-Touch App, touch X, then touch an option.
• Delete: Use this option to delete the 1-Touch App from the printer permanently.
• Hide: Use this option to remove the 1-Touch App from the Home screen. The 1-Touch App is
still available, and you can add the App to the Home screen at any time.
5. Touch Done.
Using a 1-Touch App
To use a 1-Touch App:
1. At the printer control panel, press the Home button.
2. If you are using a personal 1-Touch App, touch Login, then enter a valid login name and
password.
3. Load your original documents.
4. Touch the 1-Touch App required.
5. Do one of the following.
• If the Review Before Start option was selected during 1-Touch App setup, review the settings.
If the quantity is displayed for Copy jobs, update the number of copies, as required. Touch
Start.
• If the Start Immediately option was selected during 1-Touch App setup, the device starts
automatically.
6. To return to the Home screen, press the Home button.
XXeerrooxx
®®
AAppppss
Xerox
®
Apps are a gateway to the features and functions of your device. There are standard apps
already installed and displayed on the Home screen. There are also apps that are installed as
standard but are hidden when your device is used for the first time.
For more information about customizing the Home screen and the apps features, refer to Customize
and Personalize.
81

Xerox VersaLink C7130 Specifications

General

N-up printing	2, 4, 6, 8, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	7 s
Print speed (black, normal quality, A3)	17 ppm
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	30 ppm
Optional connectivity	Bluetooth, Wireless LAN
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP Bonjour /AirPrint
Internal memory	4096 MB
Processor cores	2
Processor frequency	1050 MHz
Sound power level (standby)	41 dB
Sound power level (printing)	69 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (sleep)	0.4 W
Power consumption (standby)	94 W
Power consumption (printing)	520 W
PCL fonts	83
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Print, Scan
Maximum duty cycle	129000 pages per month
Recommended duty cycle	0 - 7000 pages per month
Number of PostScript fonts	136
Number of print cartridges	4
Page description languages	HP-GL, JPEG, PCL 5e, PCL 6, PDF, PostScript 3, TIFF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	4.4 s
Time to first copy (color, normal)	6.7 s
Copy speed (black, normal quality, A4)	30 cpm
Display	LCD
Control type	Touch
Product color	Blue, White
Display diagonal	7 \
Market positioning	Business
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supported	HP-UX 11, HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 8, Solaris 9, Solaris 9 SPARC
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Scan to	E-mail, Network folder, SMB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	297 x 431.8 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Included cartridge capacity (CMY)	9800 pages
Included cartridge capacity (black)	16100 pages
Total input capacity	620 sheets
Total output capacity	250 sheets
Paper tray 1 input capacity	520 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	130 sheets
Custom media width	88.9 - 297 mm
Custom media length	98.4 - 431.8 mm
Paper tray media types	Bond paper, Card stock, Heavy printing media, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
HDD capacity	320 GB
Browser supported	Microsoft Internet Explorer, Microsoft Edge, Mozilla Firefox, Apple Safari, Google Chrome
Languages support	Multi

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	766.5 mm
Weight	62500 g
