Xerox WorkCentre 6025

Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-13
PL 3.1 Xerographics (1/3)
PL Item Part name Part Number
1. XERO DEVE LPH BELT ASSY (PL3.2,PL3.3) REF Only
99. BELT TRANSFER 064K 93751
s6020-652
Front
ST1
ST1
ST1
ST1
(J14)
(J3) (LPH Y)
(J2) (LPH M)
(J5) (LPH C)
(J4) (LPH K)
1 (PL3.2,PL3.3)
