Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-4
Using the Parts List
Only parts showing part numbers are available for ordering by support. Parts not showing part
numbers are available on the parent assembly.
• Item: The callout number from the exploded part diagram.
• Name/Description:
The name of the part to be ordered and the number of parts supplied per
order.
• Part Number: The material part number used to order that specific part.
• Parts identified throughout this manual are referenced PL#.#.#; For example, PL3.1.10 means the
part is item 10 of Parts List 3.1.
• A Black triangle preceding a number followed by a parenthetical statement in an illustrated parts
list means the item is a parent assembly, made up of the individual parts called out in
parentheses.
• The notation “with X~Y” following a part name indicates an assembly that is made up of
components X through Y. For example, “1 (with 2~4)” means part 1 consists of part 2, part 3, and
part 4.
• An asterisk (*) following a part name indicates the page contains a note about this part.
• The notation “J1<>J2 and P2” is attached to a wire harness. It indicates that connector Jack 1 is
attached to one end of the wire harness and connector J2 is attached to the other end that is
plugged into P2.
• Fastener location and type are indicated using designators listed in the following table. Refer to
“Fastener Types” on page 4-4” for a complete list of fasteners used, and “Hardware Kit” on
page 5-98 for fasteners available in the Hardware Kit.
Designator Fastener Type
E E-ring
KL K-clip
ST Screw, self-tapping
SM Screw, sheet metal
To Next Page
