Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-64
PL Item Parts name Part Number
1. DISPENSER ASSY (with 2-11, 18, 19) --
2. HARNESS ASSY DCKR (J13-TONER CRUM Y,M,C,K) --
3. KEY HW K 029E 53810
4. KEY HW YMC 029E 53800
5. FRAME DISP --
6. GEAR IDLER 23 807E 32140
7. CLUTCH ASSY ONEWAY 005K 10071
8. CONDUCTOR GND MOT --
9. MOTOR ASSY DISP 127K 61370
10. FRAME MOTOR --
11. GEAR IDLER 34 807E 32130
12. COVER CONNECTOR 822E 13060
13. TONER CARTRIDGE Y START --
14. TONER CARTRIDGE M START --
15. TONER CARTRIDGE C START --
16. TONER CARTRIDGE K START --
17. CLEANER ASSY 042K 94281
18. HARNESS ASSY FSR TEST (J206-J208) --
19. HARNESS ASSY DISPENSE MOT (J20-J200,J201) --
