4 Specification.
Content Specs.
Dimension. 80mm x 60mm x 25mm
Weight 100g
Network GSM/GPRS
Band 850/900/1800/1900Mhz or 900/1800/1900Mhz
GPS chip SIRF3 chip
GPS sensitivity -159dBm
GPS accuracy 5m
Time To First Fix
Reacquisition
0.1s Cold status 45s
Warm status 35s
Hot status 1s
Car charger
12—24V input
5V output
Battery Chargeable changeable 3.7V 1100mAh Li-ion battery
Standby 50hours
Storage Temp. -40°C to +85°C
Operation Temp. -20°C to +55°C
Humidity 5%--95% non-condensing
5 SIM card installation
Make sure that there is no call transfer and call display is on, and PIN code off.
Steps:
1. Use a pen to open the SIM card slot
2. Put a SIM card into the slot.
3.Insert the slot with SIM card into the tracker.
Use a pen point in the SIM card
lockhole to o
