Nut Hole for Mounting Bracket
((1/4 inch, depth < 8 mm))
Camera
Projector Lens
Power Button
(Press to turn on the projector)
Speaker
Rubber Feet
Air Inlet
Air Outlet
Product Overview
Caution:
Do not look directly into the projection lens to avoid eye damage as
this projector emits strong light during use.
Do not place any objects within a range of 20 cm around the air
inlet and outlet to avoid affecting the heat dissipation and causing
damage or posing hazards.
If mounting is required, please purchase a compatible mounting
bracket with screws meeting the following specifications: a
diameter of 1/4 inch and a length of less than 8 mm.
Retain the original packaging for future storage or transportation.
03
Headphone
Port
USB 2.0
Protocol Port
DC Port
HDMI Signal
Input Port
HDMIUSB DC IN
