Xilinx Alveo U250 Getting Started Guide

IMPORTANT! Ne débranchez pas le connecteur auxiliaire d'alimentaon des cartes Alveo™ pendant
qu’elles sont sous-tension (“hot-plug” n'est pas autorisé).
Wichg! Trennen Sie den Alveo™-Stromanschluss Karten Alveo im eingeschalteten Zustand nicht (Hot-
Plug ist nicht zulässig).
The following procedure is a guide for the Xilinx
®
Alveo™ Data Center accelerator card
installaon. Consult your computer documentaon for addional informaon.
1. Host power supply must be powered o.
2. For enclosed computers, open your computer by removing the casing.
3. If necessary, remove the two adjacent PCIe
®
x16 slot covers corresponding to the PCIe x16
slot in which you are installing the Alveo card.
4. Plug the Alveo card in the PCIe x16 slot on the motherboard.
5. Plug AUX Connector aer the card has been inserted in PCIe
®
slot, ensure the plug is
mechanically xed (with the click).
IMPORTANT! Operaon of the Alveo™ cards only with AUX Connector is not allowed.
IMPORTANT! Le fonconnement des cartes Alveo™ uniquement avec le connecteur auxiliaire n'est
pas autorisé.
Wichg! Der Betrieb von Alveo™-Karten nur mit AUX Connector ist nicht zulässig.
The card has an 8-pin female PCIe Aux Power Connector.
For acvely cooled cards, connect the power cable to the Aux power connector at top of the
card as shown in the following gure.
Chapter 3: Card Installation Procedures
UG1301 (v1.3) February 12, 2019 www.xilinx.com
Getting Started with Alveo Accelerator Cards 14
Send Feedback
