Xilinx Alveo U250

Chapter 2
Unpacking
Product Registration
IMPORTANT! To receive updates, register your product at hps://www.xilinx.com/products/design-
tools/soware-zone/sdaccel.html#gengstarted.
IMPORTANT! Pour recevoir les mises à jour, enregistrez votre produit sur hps://www.xilinx.com/
products/design-tools/soware-zone/sdaccel.html#gengstarted.
Wichg! Um Updates zu erhalten, registrieren Sie ihr Produkt unter hps://www.xilinx.com/
products/design-tools/soware-zone/sdaccel.html#gengstarted.
Accelerator Cards Overview
Card Interfaces and Details
Alveo™ cards are available in both passive and acve cooling conguraons; see Passive and
Acve Cooling Cards. The interfaces of each are idencal, except the fan included on acve
cooled cards. The card includes the following interfaces, and are shown in the following gure:
1. A PCI Express
®
card connector.
2. An Auxiliary power connector. This connector is shown in gures 4 and 5.
3. Two QSFP interfaces. Currently these interfaces are not supported by the shell.
4. A Micro-USB connector for maintenance purposes.
5. A fan for the acve cooled card conguraon.
WARNING
! Hazardous moving parts. Keep away from fan blades.
ATTENTION! Pièces mobiles peuvent etre dangereuses. Éloignez-vous des lames du venlateur.
