Xilinx Artix-7 FPGA AC701 User Manual

6 www.xilinx.com AC701 Getting Started Guide
UG967 (v3.0) July 10, 2013
Introduction
This Getting Started Guide is divided into two sections:
• Basic Hardware Bring-up: Enables hands-on operation of all the features in the BIST
as well as evaluation of Analog Mixed Signal (AMS) using the AMS101 evaluation
card.
• Advanced Bring-up: Enables hands-on operation with the base TRD, which features
PCIe®, DDR3 memory, AXI stream interconnect, and AXI virtual FIFO controller IP
cores—all supported through a custom evaluation graphical user interface (GUI).
AC701 Evaluation Kit Content
• AC701 evaluation board featuring the XC7A200T FPGA
• Targeted reference design featuring DDR3, PCIe, and DMA
• Including a full license for the Northwest Logic DMA
• AMS101 evaluation board
• Full seat Vivado® Design Suite: Design Edition
• Device-locked to the Artix-7 XC7A200T FPGA
• Additional downloadable content, including:
• Reference designs, design examples, and demos
• Board design files
• Extensive documentation
• Documentation
• Hardware User Guide
• Printed Getting Started Guide
• Reference Design User Guide
• 12V AC-adapter power supply
• Cables
• RJ45 Ethernet cable
•HDMI™ cable
• USB-A to USB-micro-B cable used for JTAG programming
• USB-A to USB-mini-B cable used for UART communication with board
• Software and reference designs, demos, and documents to quickly get started
• The BIST files (RDF0220) can be found at www.xilinx.com/ac701
in the Docs &
Designs tab.
• All user guides, board files, and tutorials are available as downloads from
www.xilinx.com/ac701
The tutorials and reference designs available on the AC701 Web page can be used to
further explore the capabilities of the AC701 and the Artix-7 FPGA. For additional
information, see the Artix-7 Family FPGAs Product Table
. For the most up-to-date
information on the tutorial content provided with the AC701 Evaluation Kit, see the AC701
Reference Design Web page by visiting www.xilinx.com/ac701
and clicking the Docs &
Designs tab.

Xilinx Artix-7 FPGA AC701 Specifications

General

Logic Cells	215, 360
DSP Slices	740
Block RAM	13, 140 Kbits
PCIe Interface	Gen2 x4
DDR3 Memory	1 GB
Ethernet	10/100/1000 Mbps
Flash Memory	128 Mb
Form Factor	ATX
FPGA Device	XC7A200T-2FBG676C
USB	USB-JTAG/UART
Configuration	SPI Flash, JTAG
Clocking	200 MHz
Expansion Connectors	FMC
Clock Management Tiles	6
Power Supply	12V
Operating Temperature	0°C to 85°C
