AC701 Getting Started Guide www.xilinx.com 5

UG967 (v3.0) July 10, 2013

Getting Started with the Artix-7 FPGA

AC701 Evaluation Kit

Introduction

The Artix®-7 FPGA AC701 Evaluation Kit (see Figure 1) provides a comprehensive,

high-performance development and demonstration platform based on the XC7A200T

FPGA for high-bandwidth and high-performance applications in multiple market

segments. The built-in self-test (BIST), the AMS 101 evaluation card usage, and the

Artix-7 FPGA Base Targeted Reference Design (TRD) are featured in this getting started

guide.

X-Ref Target - Figure 1

Figure 1: AC701 Evaluation Kit

UG967_01_111412
