22 www.xilinx.com Spartan-6 FPGA GTP Transceiver SIS Kit (HyperLynx)
UG396 (v1.0) June 10, 2010
Appendix B: HSPICE and HyperLynx/Eldo Correlation Results
The plots are zoomed in and aligned to better highlight the correlation.
These conditions were used for the transceiver correlation:
• A data rate of 3.125 Gb/s
• PRBS7 data pattern
• No external capacitor
• No ground termination
The simulation results are provided in these sections:
• GTP REFCLK Model Correlation, page 23
• GTP Transceiver Model Correlation, page 27
