Xinje DS5F-21P5-PTA User Manual

169
P0-05
Definition of rotation
direction
0- positive mode
1- negative mode
-
0
0~1
●
1|2|3|4|5|6|7|
8|9|10
5.2.3
P0-07
First inertia ratio
1%
20P1
：
800
>20P1
：
200
0~5000
0
√
1|2|3|4|5|6|7|
8|9|10
6.2.1
P0-09.0
Forward Direction of
Input Pulse Instruction
0-Forward Pulse
Counting
1-Reverse Pulse
Counting
-
0
0~1
●
6|7
5.3.2
P0-09.2
Input pulse command
filter time
-
F
0~F
●
6|7
5.3.2
Parameter
Function
Unit
Default
value
Range
Effective
Suitable
mode
Reference
chapter
P0-09.3
Predistribution of input
pulse command filter
-
0
0~7
●
6|7
5.3.2
P0-10.0
0-CW/CCW
1-AB
2-P+D
-
2
0~2
○
6|7
5.3.2
P0-11
～
P0-12
Number of instruction
pulses per cycle
0: Electronic gear ratio
Non-0: Number of
command pulses
required for motor
rotation
1 pul
10000
0~99999999
○
5|6
5.3.1.1
P0-13
Electronic Gear
Numerator
-
1
0~65535
○
5|6
5.3.1.1
P0-14
Denominator of
Electronic Gear
-
1
0~65535
○
5|6
5.3.1.1
P0-15
Pulse frequency
corresponding to rated
speed
100Hz
1000
1~10000
○
7
5.4.3.2
P0-16
Speed command pulse
filter time
0.01ms
100
0~10000
○
7
5.4.3.3
P0-18
Encoder feedback pulse
number per turn (low bit)
0
0
0~9999
√
1|2|3|4|5|6|
7|8|9|10
5.8
P0-19
Encoder feedback pulse
number per turn (high bit)
10000
10000
0~9999
√
1|2|3|4|5|6|
7|8|9|10
5.8
P0-23
pulse offset limit
0.01 turn
2000
0~65535
√
5|6|10
5.3.1.6
P0-24
Type selection of
discharge resistance
(version 3640 and before)
0: built in
1: external
Power protection mode
of discharge resistance
(version 3700 and later)
0 - cumulative discharge
time
1 - average power mode 1
-
0
0~1
○
1|2|3|4|5|6|
7|8|9|10
5.2.6
