Xinje DS5L1-20P7-PTA User Manual

1.1.3 Performance specification
Servo unit
DS5L1 series servo driver
Applicable encoder
Standard: 17-bit/23-bit communication encoder
Input power supply
DS5L1-2□P□-PTA: single phase AC200-240V, 50/60Hz
Control mode
Three-phase full-wave rectifier IPM PWM control sinusoidal current
drive mode
Using
condition
Using
temperature
-10～+40 ℃
Storage
temperature
-20～+60 ℃
Environment
humidity
Below 90％RH (no condensation)
Vibration
resistance
4.9m/s
2
Structure
Pedestal installation
1.2 Servo motor selection
1.2.1 Model name
MS5S – 80 ST E – C S 02430 B Z - 2 0P7 – S01
Name
Rated power (KW)
0P2 0.2
0P4 0.4
0P7 0.75
Name Voltage level
2 220V
4 380V
Name Power-off brake
Empty
without
Z with
Name Shaft
A No key
B With key
Name Inertia
MS5S Low inertia
MS5G Middle inertia
MS5H High inertia
Name Seat number
60 60 seat
80 80 seat
Name Product name
ST Sine drive motor
Name Encoder type
C
Magnetic encoder
T
Photoelectric
encoder
Name Rated torque (N·m)
00630 0.637
01330 1.3
Rated speed (rpm)
3000
3000
Name
Encoder accuracy
S
Single circle 17-bit
M
Multi-circle 17-bit
U
Single circle 23-bit
L
Multi-circle 23-bit
Name Design number
S01 standard
02430 2.39
3000
Name Product name
empty No oil seal
E With oil seal
S02
Small Aviation Plug
Type
