2.4 Servo driver dimension
DS5L1-20P1-PTA, DS5L1-20P2-PTA, DS5L1-20P4-PTA Unit: mm
AC220V~400W
CN3
CN0
CN2
CHARGE
DS5L1-20P7-PTA Unit: mm
CN2
CHARGE
CN0
CN3
AC220V~750W
