Xinje DS5L1-20P7-PTA User Manual

 80 series motor installation dimensions Unit: mm
90
a80
4-
6
70h7
6
0
-0.02
M5深8
15,5
0
-0,1
3 8
35±0.5
25
19h6
2
2
LA
Motor model
LA±1
Inertia
level
Series
Normal
With
brake
MS5S-80ST-C□02430□□-20P7-S01/S02
107
144
Low
inertia
MS5
series
MS5S-80ST-C□03230□□-21P0-S01/S02
128
165
MS5H-80ST-C□02430□□-20P7-S01/S02
119
156
High
inertia
MS5H-80ST-C□03230□□-21P0-S01/S02
140
177
MS-80ST-T02430□□-20P7
150
199
-
MS-80ST-T03520□□-20P7
179
219
MS6S-80C□30B□1-20P7
117
150
Low
inertia
MS6
series
MS6S-80C□20B□1-20P7
127
160
MS6H-80C□30B□1-20P7
124
157
High
inertia
MS6H-80C□20B□1-20P7
149
182
 130 series motor installation dimensions Unit: mm
a130
145
4-
9
LA
2
5
LB
57±0.5
40
2.5
22h6
110h7
18.5
0
-0.1
6
0
-0.02
M6深15
Motor model
LA±1
LB
Inertia level
Normal
With
brake
MS5G-130STE-C□05415□□-20P8-S01
117.5
147.0
12.5
Middle inertia
MS5G-130STE-TL05415□□-20P8-S01
134.5
164.5
