Xinje DS5L1 Series User Manual

corresponding to rated
speed (5E/5L not
support)
P3-02
Analog voltage speed
filter (5E/5L not
support)
0.01ms
200
0~10000
√
1|2|4
5.4.4
P3-03
Speed instruction input
dead zone voltage
(5E/5L not support)
0.001v
0
0~500
√
1|2|4
5.4.4
P3-04
V-REF analog speed
direction(5E/5L not
support)
-
0
0~1
√
1|2|4
5.4.4
P3-05
Preset speed 1
rpm
0
-9999~9999
√
3
5.4.2
P3-06
Preset speed 2
rpm
0
-9999~9999
√
3
5.4.2
P3-07
Preset speed 3
rpm
0
-9999~9999
√
3
5.4.2
P3-09
Acceleration time
ms
Version 3720 and
before: 0
Version 3730: 200
0~65535
○
3|4|7
5.4.1.1
P3-10
Deceleration time
ms
Version 3720 and
before: 0
Version 3730: 200
0~65535
○
3|4|7
5.4.1.1
P3-12
Zero-speed clamping
mode
-
0
0~3
○
3|4|7
5.4.1.2
P3-13
Zero-speed clamping
speed
rpm
10
0~300
○
3|4|7
5.4.1.2
P3-14
Forward Maximum
Speed Instruction
Limit
rpm
4000
0~10000
○
1|2|3|4|5|6
|7|10
5.8.3
P3-15
Reverse Maximum
Speed Instruction
Limit
rpm
4000
0~10000
○
1|2|3|4|5|6
|7|10
5.8.3
P3-16
Internal Forward
Speed Limitation in
Torque Control
rpm
2000
5~10000
√
1|2
5.5.1.2
P3-17
Internal Reverse Speed
Limitation in Torque
Control
rpm
2000
5~10000
√
1|2
5.5.1.2
P3-18
Jogging speed
rpm
100
0~1000
○
1|2|3|4|5|6
|7|10
4.4.2
P3-19
forward warning speed
rpm
3000
0~10000
○
1|2|3|4|5|6
|7|10
5.8.5.4
P3-20
reverse warning speed
rpm
3000
0~10000
○
1|2|3|4|5|6
|7|10
5.8.5.4
P3-21
forward alarming
speed
rpm
4000
0~10000
○
1|2|3|4|5|6
|7|10
-
P3-22
reverse alarming speed
rpm
4000
0~10000
○
1|2|3|4|5|6
|7|10
-
P3-23
T-REF Function
Allocation
0 - Input as Torque
Instruction
1 - As a necessary
-
0
0~2
○
2|3|4|5|6|7
|10
5.7.2

Xinje DS5L1 Series Specifications

General

Brand	Xinje
Model	DS5L1 Series
Category	Servo Drives
Language	English
