Xinje DS5L1 Series User Manual

F0-00~F0-xx
0x2000~0x2063
Modbus address is added 1 in turn from 0x2000, for
example, Modbus address of F0-01 is 0x2001
F1-00~F1-xx
0x2100~0x2163
Modbus address is added 1 in turn from 0x2100, for
example, Modbus address of F1-03 is 0x2103
Note: if the following parameters are not involved in the Modbus address table, follow the address rules
in the table above.
 Group P parameter address
Parameter
Modbus address
Parameter
Modbus address
Hex
Decimal
Hex
Decimal
P0-00
0x0000
0
P0-17
0x0011
17
P0-01
0x0001
1
P0-18
0x0012
18
P0-02
0x0002
2
P0-19
0x0013
19
P0-03
0x0003
3
P0-20
0x0014
20
P0-04
0x0004
4
P0-21
0x0015
21
P0-05
0x0005
5
P0-22
0x0016
22
P0-06
0x0006
6
P0-23
0x0017
23
P0-07
0x0007
7
P0-24
0x0018
24
P0-08
0x0008
8
P0-25
0x0019
25
P0-09
0x0009
9
P0-26
0x001A
26
P0-10
0x000A
10
P0-27
0x001B
27
P0-11
0x000B
11
P0-28
0x001C
28
P0-12
0x000C
12
P0-29
0x001D
29
P0-13
0x000D
13
P0-30
0x001E
30
P0-14
0x000E
14
P0-31
0x001F
31
P0-15
0x000F
15
P0-32
0x0020
32
P0-16
0x0010
16
P0-33
0x0021
33
Parameter
Modbus address
Parameter
Modbus address
Hex
Decimal
Hex
Decimal
P1-00
0x0100
256
P1-15
0x010F
271
P1-01
0x0101
257
P1-16
0x0110
272
P1-02
0x0102
258
P1-17
0x0111
273
P1-03
0x0103
259
P1-18
0x0112
274
P1-04
0x0104
260
P1-19
0x0113
275
P1-05
0x0105
261
P1-20
0x0114
276
P1-06
0x0106
262
P1-21
0x0115
277
P1-07
0x0107
263
P1-22
0x0116
278
P1-08
0x0108
264
P1-23
0x0117
279
P1-09
0x0109
265
P1-24
0x0118
280
P1-10
0x010A
266
P1-25
0x0119
281
P1-11
0x010B
267
P1-26
0x011A
282
P1-12
0x010C
268
P1-27
0x011B
283
P1-13
0x010D
269
P1-28
0x011C
284
P1-14
0x010E
270
