Xinje XC1 Series User Manual

Appendix special soft device list
ID
Counter
ID
Function
Description
M8150
C600
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8151
C602
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8152
C604
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8153
C606
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8154
C608
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8155
C610
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8156
C612
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8157
C614
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8158
C616
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8159
C618
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8160
C620
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8161
C622
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8162
C624
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8163
C626
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8164
C628
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8165
C630
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8166
C632
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8167
C634
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8168
C636
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
M8169
C638
“Count Interruption Finished” Flag
Set flag ON when count interruption finish
ID
Pulse ID
Function
specification
M8170
PULSE_1
“sending pulse” flag
Being ON when sending the pulse,
M8171
overflow flag of “32 bits pulse
sending”
When overflow, Flag is on
M8172
Direction flag
1 is positive direction, the correspond
direction port is on
M8173
PULSE_2
“sending pulse” flag
Being ON when sending the pulse,
M8174
overflow flag of “32 bits pulse
sending”
When overflow, Flag is on
M8175
Direction flag
1 is positive direction, the correspond
direction port is on
M8176
PULSE_3
“sending pulse” flag
Being ON when sending the pulse,
M8177
overflow flag of “32 bits pulse
When overflow, Flag is on
“High Speed Counter Interruption Finished” Flag (M8150-M 8169)
Pulse output (M8170~M8238)
