Xinje XC1 Series User Manual

8 expansion devices
Distinguish Ratio
1/16383(14Bit); the convert data is
stored in PLC in form of Hex. (14Bit)
1/4095(12Bit); the convert data is stored
in PLC in form of Hex. (14Bit)
PID Output Value
0~K4095
Integral precision
0.8%
Convert Speed
20ms/CH
3ms/CH
Power Supply
DC24V±10%, 100mA
0V
24V
C1
C0
AI0 VI1 C2 AI2 VI3
AI3C3VI2A11VI0
VO0 VO1
AO1C1AO0C0
CH
NAME
SIGNAL
CH
NAME
SIGNAL
CH0
AI0
Current analogue input
CH1
AI1
Current analogue input
VI0
Voltage analogue input
VI1
Voltage analogue input
C0
COM of CH0
C1
COM of CH1
CH2
AI2
Current analogue input
CH3
AI3
Current analogue input
VI2
Voltage analogue input
VI3
Voltage analogue input
C2
COM of CH2
C3
COM of CH3
CH0
AO0
Current analogue output
CH1
AO1
Current analogue output
VO0
Voltage analogue output
VO1
Voltage analogue output
C0
COM of CH0
C1
COM of CH1
-
24V
+24V power supply
0V
COM of power supply
8-3-3．XC-E4AD
Terminal Arrangement
3
Brief Introduction
1

Xinje XC1 Series Specifications
