Xinje XC1 Series User Manual

8 expansion devices
 Input Specification
Input Items
Content
Input signal’s voltage
DC24V±10%
Input signal’s current
7mA/DC24V
Input ON current
Up to 4.5mA
Input OFF current
Low than 1.5mA
Input response time
About 10ms
Input signal’s format
Contact input or NPN open collector transistor
Circuit insulation
Photo-electricity coupling insulation
Input action’s display
LED light when input ON
 Relay output
Input Items
Content
Internal power
Below AC250V, DC30V
Circuit insulation
Mechanism insulation
Action denote
LED indicate lamp
Max load
3A
3A
80VA
80VA
100W
100W
Min load
DC5V 2mA
Response time
OFF  ON
10ms
ON  OFF
10ms
 Transistor Output
Input Items
Content
Internal power
Below DC5~30V
Circuit insulation
Optical coupling insulation
Action denote
Indicate lamp LED
Max load
0.8A
0.8A
12W/DC24V
12W/DC24V
1.5W/DC24V
1.5W/DC24V
Module Specification
2
Power Supply Specification
DC24V (32 I/O expansions is AC220V)
