Appendix special soft device list
COMMENTS AND DESCRIPTIONS
Display temperature
(unit: 0.1℃)
(X input which returns
to main unit)
(0 is connect, 1 is
disconnect)
PID auto tune error bit
(0 is normal, 1 is
parameters error)
Auto tune PID control
bit
Auto tune activate signal, enter auto tune stage if being set to be 1;
when auto turn finish, PID parameters and temperature control cycle value are refreshed,
reset this bit automatically.
Users can also read its status; 1 represents auto tune processing; 0 represents no atto tune or
auto tune finished
PID output value
(operation value)
Digital output value range: 0～4095
If PID output is analogue control (like steam valve open scale or thyistor ON angle),
transfer this value to the analogue output module to realize the control requirements
Via PID auto tune to get the best parameters;
If the current PID control can’t fulfill the control requirements, users can also write the PID
parameters according to experience. Modules carry on PID control according to the set PID
parameters.
PID operation activates between ±Diff ranges. In real temperature control environments, if
the temperature is lower than , PID output the max value; if the temperature
is higher than , PID output the mini value;
(sample temperature+ Temperature difference δ)/10=display temperature value. Then
temperature display value can equal or close to the real temperature value. This parameter
