Xinje XC1 Series User Manual

2 The Specifications and Parameters of CPU
C600~C619: single phase high speed counter
C620~C629: dual-phase high speed counter
C630~C639：AB phase high speed counter
Spec.
16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~＋2147483647
Data Register (D)
9024
words
D0~D3999
【D4000~D7999】
※
5
For Special Use
※
6
D8000~D9023
Flash ROM Register (FD)
4096
words
FD0~FD3071
For Special Use
※
6
FD8000~FD9023
Expansion's Register (ED)
※
7
16384
words
ED0~ED16383
High Speed Dispose
Ability
High speed counter, pulse output, external interruption
Password Protection
6 bits ASCII
Self-diagnose Function
Power on self-check、monitor the timer、grammar check
Items
Specifications
Program Executing Form
Loop scan form
Program Form
Instruction、Ladder
Dispose Speed
0.5 us
Power Off Retentive
Use Flash ROM
User's program space
※
1
96K
I/O points
※
2
Total I/O
24
32
48
60
Input
14
X0~X15
18
X0~X21
28
X0~X33
36
X0~X43
Output
10
Y0~Y11
14
Y0~Y15
20
Y0~Y23
24
Y0~Y27
Internal Coils (X)
※
3
544 points: X0~X1037
Internal Coils (Y)
※
4
544 points: Y0~Y1037
Internal Coils (M)
8768
points
M0~M3999
【M4000~M7999】
※
5
For Special Use
※
6
M8000~M8767
Flow (S)
1024
points
S0~S511
【S512~S1023】
