XLT Ovens X3G-3255 Series - HOOD ASSEMBLY; Hanging Hood from Ceiling Joists

Technical Support US: 888-443-2751 Technical Support INTL: 316-943-2751
77
HOOD ASSEMBLY
69 5/8
[1768]
All thread provided by others
NOTE
This measurement is from the finished floor to the bottom of the suspended hood.
Hood Must Be Suspended From Ceiling Joists
DANGER
Hang Hood From Ceiling Joists
NOTE: All dimensions in inches [millimeters], ± 1/4 [6], unless otherwise noted.
