14
DE
Thema:
XOMAX
XM-RSU247B
Anschlussschema Cinch Anschlüsse
Anschlussschema Cinch Anschlüsse
10
z.B.
Verstärker
optional
Lautsprecher
hinten links
vorne links
hinten rechts
vorne rechts
Audioausgang HR
Audioausgang HL
Audioausgang VL
Audioausgang VR
Radio-Antenne
Passiv
