1. Notice to XPENG Owners
8
Intelligent power unit (IPU)
AC charging port Refer to Page 11
CCS/DC-DC converter
Traction battery Refer to Page 9
DC charging port Refer to Page 12
A/C compressor
Drive motor
Warning
●
The orange wiring harnesses are
HV ones. It is forbidden to touch
or disassemble any HV wiring
harnesses and related HV parts,
otherwise there is a danger of
electric shock!
EV System Layout
To Next Page
