Troubleshooting
Module Programming
Solid The bus type cannot be detected.
Make sure the connections to the data bus are correct
and insert the key in the ignition switch.
Flashing
quickly
The vehicle type cannot be
detected.
Insert the key in the ignition switch and turn to the ON
position. You may need to wait up to 10 seconds.
Flashes slowly Waiting for keyless.
Remove the key from the ignition switch and press a
keyless button, or the Programming button.
Solid for 3
seconds
Module was successfully
programmed or is already
programmed.
Normal operation.
Flashes once
quickly
Modules was reset. Normal operation.
Off Module has no power. Check the power connections.
Active Ground While Running
Solid Incorrect behavior.
Data is not processing correctly. Disconnect the power
from the module and power up.
Off Ground while running (status) off.
Make sure the module was programmed, i.e. the D2D
harness is properly connected or thegroundwhile
running (status) wire is connected (if in W2W mode).
Flashes for 1
second
A command is processing. Normal operation.
Flashes Ground while running (status) on. Normal operation.
Inactive Ground While Running
Off Ground while running (status) is off. Normal operation.
Flashes for 1
second
A command is processing. Normal operation.
Solid Incorrect behavior.
Data is not processing correctly. Disconnect the power
from the module and power up.
Flashes Ground while running (status) on.
Module did not receive ground while running (status) off.
Make sure the D2D harness is properly connected or
the ground while running (status) wire is not shorted to
ground.
