Xpresskit XK09 User Manual

Rev.: 20110111
Platform: XK09
Firmware: CHRYSLER
© 2011 Directed Electronics. All rights reserved.
Vehicle Canbus Integration System
The Mobile Integration Systems
Page 8
Installation Type 6
* The Tach wire is an optional connection required on some remote starters not supporting tach signal in D2D.
Not required in D2D mode.
Programming Button
4
4
4
20
2
XK09
1: (+) 12 V
2: RX
3: (-) Ground
4: TX
2: Green: (-) Door/Trunk Sense Output
1: Violet/White: (AC) Tach Output*
Remote
Starter
3: -
4: -
(AC) Tach Input*
(-) Door/Trunk Sense Input
Parking Lights
(-) Neutral Safety (DEI platforms only)
(-) Hood
(+) Starter
15: Yellow
13: Violet/Brown: Multiplex Output
17: Orange
18: Green: J1850
9: Red: (+) 12 V
1: Blue/White: (-) GWR (status)
3: Light Green: (-) Lock Input
5: Blue: (-) Unlock Input
6: Red/White: (-) Trunk Input
7: Violet: (+) Starter Input
8: Pink: (+) Ignition Input
(+) 12 V
RX
(-) Ground
(-) Ground
TX
(+) 12 V
(+) Ignition Output
(+) Starter Output
(-) Trunk Output
(-) Unlock Output
(-) Lock Output
(-) GWR (status)
10: Black: (-) Ground
(+) 12 V
(-) Ground
16
Module-Sentry Key
Remote Entry
Pin 4, Sentry Key
(+) Ignition
Pin 2, J1850
Violet/Brown, Pin 2
51
Facing view
