8
COMPOSITE
FRONT SOLID
AXLE
1.
GEAR
DIFFERENTIAL
&
FRONT
SOLID
AXLE
902310
SH M3x10
941015
BB 10x15x4
941015
BB 10x15x4
OI
L
OI
L
BEARING OIL
(HUDY #106230)
BEARING OIL
(HUDY #106230)
#304900
GEAR DIFFERENTIAL
#305003
ALU DIFF 34T + 38T PULLEY
#305105
XRAY ALU MUL
TI-DIFF™
#305188
COMPOSITE SOLID AXLE 38T PULLEY
CUT
AW
A
Y VIEW
38T
Pulley
7
9
