Xray XB4 User Manual

23
ROLL CENTER
CAMBER
➊
1:1
ALU CONICAL SHIM
#362280 SILVER INCLUDED
#362280-K BLACK OPTION
#362280-O ORANGE OPTION
4. FRONT TRANSMISSION
2x
2x
2x
L=R
L=R
L=R
32.5mm
2x
L=R
9mm 20mm
10mm
THREAD
8mm
THREAD
DO NOT OVERTIGHTEN
NOTE
ORIENTATION
CONICAL SHIM 2mm
NOTE
ORIENTATION
NOTE
ORIENTATION
➋
SHORT
LONG
362280
CON. SHIM 3x6x2
901306
SB M3x6
960030
N M3
Check for free
movement
INITIAL SETTING
DETAIL
L=R
If the C-hub does not move
freely, use a HUDY Arm
Reamer to resize the hole.
(HUDY #107633)
ARM REAMER
ALU NUTS M3
#296530-B BLUE OPTION
#296530-K BLACK OPTION
#296530-O ORANGE OPTION
#960031 SILVER INCLUDED
10mm
THREAD
8mm
THREAD
THREAD
THREAD
Install the pivot balls with Professional
Multi Tool (HUDY #183011)

Xray XB4 Specifications

General

Drive	4WD
Suspension	Independent
Type	Buggy
Battery Type	LiPo
Differential	Gear
Motor Type	Brushless
Class	Off-Road
Radio System	2.4 GHz
Scale	1:10
