DP224/6 Operators Manual Page 31
System Sub-Menu
System Status
Displays unit information including software version and temperature.
Curr. Temp. = current temperature in degrees Celsius.
Max1. Temp. = maximum temperature this session.
Max2. Temp. = maximum temperature ever reached.
LCD Contrast
Adjusts the LCD contrast from 0 to 100.
LED Brightness
Adjusts the LED brightness from 1 to 15.
Temperature Alarm
Sets a temperature warning between 20 and 80°C. The default screen will flash
‘ALARM. Temp = n°C’ when the specified temperature is reached. (N.B. the warning
does not affect the units’ performance in any respect.)
Program Update
Loads a new version of software from a PC card. Updating the software will not
affect any user memories stored in the unit.
Wake-up Time
Sets how the unit starts up with one of the following options.
0 to 60 seconds: Waits the specified time before unit wakes up.
Mute hold: Turns on and holds all output mutes when turned on.
(N.B. Wake-up is a slow ramp in level for about 5 seconds.)
Output Meters
Selects whether the output meters are pre or post mute. If the meters are set to
read pre-mute, they will still show the level, even if the channel has been muted.
Filter Q or BW
Selects whether ‘Q’ or Bandwidth is displayed in the parametric screens.
Delay Time/Distance
Selects whether delay is displayed in milliseconds, metres, or feet.
Unit Cloning
This option allows a unit to be completely ‘backed up’ or ‘restored’ to another unit.
Selects store or recall ‘clone’ data using a PC card. Cloning stores all input memories
(40), all user crossovers (9) and all menu options to the PC card.
