XTA DP6i User Manual

DP6i Operators Manual Page 35
Appendix 2: Default X-over settings and names for all formats.
X-over Output 1 Output 2 Output 3 Output 4 Output 5 Output 6
2x2 way+Ms
Low High Low High Msub Aux
120Hz – 1k82Hz 1k82Hz – 22kHz 120Hz – 1k82Hz 1k82Hz – 22kHz 24.8Hz – 120Hz <10Hz – 22kHz
2 x 3 way
Low Mid High Low Mid High
22.1Hz – 120Hz 120Hz – 1k82Hz 1k82Hz – 22kHz 22.1Hz – 120Hz 120Hz – 1k82Hz 1k82Hz – 22kHz
4 way + 2
Low LoMid HiMid High Aux Aux
15Hz – 149Hz 149Hz – 1k31Hz 1k31Hz – 8kHz 8kHz – 22kHz 20.1Hz – 22kHz 20.1Hz – 22kHz
5 way + 1
Sub Low LoMid HiMid High Aux
15Hz – 80.3Hz 80.3Hz – 180Hz 180Hz – 1k31Hz 1k31Hz – 8kHz 8kHz – 22kHz 20.1Hz – 22kHz
6 way
LoSub Sub Low LoMid HiMid High
15Hz – 80.3Hz 80.3Hz – 149Hz 149Hz – 1kHz 1kHz – 4kHz 4kHz – 10k1Hz 10k1Hz – 22kHz
Note: All filters set to 24dB Linkwitz-Riley.
