XTA DP6i User Manual

Page 4 DP6i Operators Manual
Contents
Important Safety Information 5
Unpacking the DP6i
DP6iDP6i
DP6i 6
Introduction 7
Front Panel Familiarisation 9
Operating the DP6i
DP6iDP6i
DP6i 11
Note about operation with Windows
TM
software. 11
Start-up procedure 11
Preliminary Set-up 11
Quick Memory Recall Keys 11
Mute Unit Key 12
Interface Operation Guides 13
RS232 Interface 13
RS232 Connection (Single Unit) 14
Shadow ID Numbers 14
RS485 Interface 16
RS485 Connection 17
Midi Interface 18
Midi Connection 18
GPI Interface 19
Locking the Unit Remotely 20
DP6i Configurations 21
Introduction 21
2 x 2 way with Mono Sum 21
2 x 3 way 22
4 way + 2 23
5 way + 1 24
6 way 25
AES / EBU Operation Guide 26
AES / EBU Connections 26
Operating Notes 27
Operating Level 27
Grounding 27
Crossover Filter Slopes 28
Time Alignment 28
Output Limiters 29
Setting Accurate Limiter Thresholds 30
Specifications 32
Warranty 33
Options and Accessories 33
Appendices 34
Appendix 1: Limiter threshold in dB to Vrms lookup table. 34
Appendix 2: Default X-over settings and names for all formats. 35
Appendix 3: Additional Information: General Purpose Interface 36

XTA DP6i Specifications

General

Brand	XTA
Model	DP6i
Category	Controller
Language	English
