DS8000 Operator’s Manual Page 24
Factory fit options
The following options are available for your unit.
Please note that these are factory-fit only options and must be ordered at the time of
purchase.
Convert electronic ally balanced inputs to transformer balanced inputs:
This is performed on all eight channels as a group and cannot be applied to individual inputs.
Convert electronic ally balanced rear outputs to transformer balanced outputs:
This is performed on all eight outputs as a group and cannot be applied to individual outputs.
Note that this option drops the gain on these outputs by 10dB so they run (with the gain
control set to 0dB) at —10dB through the unit.
Convert transformer balanced front outputs to electronically balanced outputs:
This is performed on all sixteen outputs as a group and cannot be applied to individual
outputs. Note that this option increases the gain on these outputs by 10dB so they run (with
the gain control set to 0dB) at 0dB through the unit.
AES digital output board:
This option adds 96k 24bit high quality analogue to digital conversion to each input channel
and provides additional AES-3 output streams via a DB25 connector on the rear panel, along
with optional word clock sync (selectable to be an output or input).
