Xtant 301A User Manual

Xtant 301a SPECIFICATIONS
Frequency Response 5 Hz to 50 kHz +/– 3 dB
Number of Channels 1
Watts per Channel @ 4Ω 1 x 300
Watts per Channel @ 2Ω 1 x 300
Distortion (THD) < .04%
Signal to Noise Ratio > 100 dB
Damping Factor > 200 @ 100 Hz with 4Ω Load
Input Sensitivity 100 mV to 8.5 V RMS Unbalanced Source
100 mV to 17 V RMS Balanced Source
Input to Line Output Gain 0 dB
+/–
20 dB, Selectable in 10 dB Steps
Line Outputs: Yes
Crossover CM12LP Included
Module Ports 2 for Amplifier and 1 for Line Outputs
Power Supply Fully Regulated, Pulse Width Modulated
Operational Voltage 11 to 15 Volts
Fusing No On-Board Fuse
Fusing Requirement 50 Amp
Size (L x W x H) 14.5 x 7.6 x 2.25”
Warranty Limited 4 Year Parts and Labor
SEE PAGE ELEVEN OF THIS MANUAL FOR COMPLETE DETAILS
6

Xtant 301A Specifications

General

Brand	Xtant
Model	301A
Category	Amplifier
Language	English
