Xtant 603x SPECIFICATIONS
Frequency Response 5 Hz to 50 kHz +/– 1 dB
Number of Channels 3
Watts per Channel @ 4Ω 2 x 75 + 1 x 150
Watts per Channel @ 2Ω 2 x 150 + 1 x 300
Bridged Mono @ 4Ω (Stereo Channels) 1 x 300
Recommended Load
(stereo channels) >2Ω Stereo / >4Ω Bridged
Recommended Load
(Mono channel) >2Ω
Distortion (THD) < .04%
Measured: 20 Hz to 20 kHz at rated power, all channels driven 4Ω
Signal to Noise Ratio > 100 dB
Measured: A-weighted in 20 kHz noise bandwidth @ 1 volt sensitivity
Damping Factor > 200 @ 100 Hz with 4Ω load
Input Sensitivity 100 mV to 8.5 V RMS Unbalanced Source
100 mV to 17 V RMS Balanced Source
Input to Line Output Gain 0 dB +/– 20 dB, Selectable in 10 dB steps
On-Board Crossover 12 dB (Butterworth) or
24dB (Linkwitz-Reily)
Module Port(s) 4
Power Supply Fully Regulated, PWM
Operational Voltage 11 to 15 Volts
Fusing Requires 100 Amp
Warranty Limited 4 Year Parts and Labor
SEE PAGE ELEVEN OF THIS MANUAL FOR COMPLETE DETAILS
