Xterra EU150 User Manual

8
EU150 Hybrid Elliptical Upright Bike
1. Attach the Left Bottom Handlebar (14) to the left side axle of
the Front Post (13). Secure using one D Type Washer (36),
one Washer (35), one Spring Washer (34) and one Hex Head
Screw(33). Attach the PVC Cap (32) onto the Hex Head
Screw(33).
2. Repeat for the Right Bottom Handlebar (15) to the right side
axle of the Front Post (13).
EU150 Assembly Instructions
Hardware Step 3
Bottom Handlebars
2 D Type Washers (#36)
2 Washers (#35)
2 Spring Washers (#34)
2 Hex Head Screws (#33)
2 PVC Caps (#32)
3

Xterra EU150 Specifications

General

Brand	Xterra
Model	EU150
Category	Elliptical Trainer
Language	English
