EU150 Hybrid Elliptical Upright Bike
5
EU150 Assembly Pack Checklist
Part No. Description Q’ty
6 Curved Washer Ф22*Ф10 4
7 Dome Nut M10 4
8 Carriage Bolt M10*75 4
30 Allen Screw M8*16 6
31 Curved Washer Ф22*Ф8 6
32 PVC CAP 6
37 Carriage Bolt 4
38 Allen Screw M6*12 4
39 Hex Head Bolt M10*78 2
40 Sleeve 2
41 Washer Φ10*Φ22 6
42 Nylon Nut M10 6
44 Carriage Bolt M10*45 4
45 L/R Hinge Bolt (L/R) 1/1
46 Wave Washer Ф16 2
47 Washer Ф27*Ф13 2
48 L/R Lock Nut (L/R) 1/1
Allen Key 4mm 1
Allen Key 6mm 1
Allen Key 8mm 1
Allen Wrench 2
Note: Above parts are all the parts needed to assemble this machine. Before you start to assemble,
please check the hardware packing to make sure they are included.
