Xterra FS400 - Assembly Pack Checklist; Hardware Step 1 Components

4
FS400 Elliptical
FS400 Assembly Pack Checklist
Hardware Step 1
#97. Ø8 x Ø23 x 1.5T
Flat Washer
(4 pcs)
#70. 5/16” x 15mm
Hex Head Bolt
(6 pcs)
#102. Ø8 x Ø23 x 1.5T
Curved Washer
(2 pcs)
#150. Ø10 x Ø23 x 1.5T
Curved Washer
(2 pcs)
#147. Ø8 x Ø26 x 2.0T
Flat Washer
(2 pcs)
Hardware Step 2
#151. 5/16” x UNC18 x 15L
Button Head Socket Bolt
(2pcs)
#148. 3/8” x UNC16 x 3”
Carriage Bolt
(2 pcs)
#149. 3/8” x UNC16 x 12.5T
Cap Nut (2 pcs)
