2018/5/4V1.0+V1.0 11
3.2. Hardware Pack
ITEM Description Qty ITEM Description Qty
a
Inner hexagon steel screw M10x25 of
umbrella head
8 j
Umbrella head crossed screw (tail cutting)
M4x15
2
b Spring washer M10 16 k
Type L hexagon wrench + crossed
screwdriver 5x35x115mm
1
c Washer φ10xφ25x2.0t 16 l Type T wrench 6mm 1
d
Inner hexagon steel screw M8x20 of
socket head
4 m Type T wrench 10mm 1
e Spring washer M8 8 n Power cord switch sleeve 1
f Washer Φ8xΦ19x2.0t 8 o Umbrella head crossed screw M4x10 2
g
Inner hexagon screw M10x20 of
umbrella head, stainless steel
8 p Spring washer M4 2
h
Inner hexagon steel screw M8x75 of
umbrella head
4 q CABLE adapter 1
i
Umbrella head crossed screw (tail
cutting) M5x15
4
To Next Page
