PARTS LIST
Key Part Number DESCRIPTION QTY
01 0612001 Main frame 1
02 0612002 Front pos
t
1
03 0612003 Seat pos
t
1
04 0612004 Handlebar 1
05 0612005 Front stabilizer 1
06 0612006 Rear stabilizer 1
07 0612007 Extension sensor wire 1
08 0612008 Crank w/pulle
y
1
09 0612009 Carria
g
e bolt M8x60L 4
10 0612010
A
llen screw M8x30L 2
11 0612011
A
llen screw M8x15L 4
12 0612012 Sensor wire 1
13 0612013 Lower tension cable 1
14 0612014 Seat cushion KX6614 1
15 0612015 Flat washer φ8.5xφ20 3
16 0612016 Screw M5x10L 2
17 0612017 N
y
lon nut M8 3
18 0612018 Computer 1
19 0612019 Curved washer φ8.5xφ20 8
20 0612020 Tension knob w/ upper tension cable 1
21 0612021 Sprin
g
washer M8 2
22 0612022 Domed nut M8 4
23 0612023 Left pedal 1
24 0612024 Ri
g
ht pedal 1
25 0612025 Cover for handlebar 1
26 0612026 Club knob M12 1
27 0612027 Pulse wire 2
28 0612028 Gromme
t
2
29 0612029 Ri
g
ht chain cover 1
30 0612030 Crank cover 2
31 0612031 End cap for handlebar 2
32 0612032
A
d
j
ustment bolt 1 1
33 0612033 Bushin
g
for seat pos
t
1
34 0612034 End cap for rear stabilizer 2
35 0612035 End cap for front stabilizer 2
36 0612036 Fl
y
wheel w/ ma
g
net assembl
y
1
37 0612037 Self-tappin
g
screw ST4.2x12L 2
38 0612038 Curved washer φ5.5xφ20 1
39 0612039 Self-tappin
g
screw ST3.2x12L 1
40 0612040 Self-tappin
g
screw ST4.2x20L 8
41 0612041 Foam
g
rip for handlebar 2
42 0612042 Belt 1
43 0612043 EVA pad 1
44 0612044 Cross head self-tappin
g
screw ST4.2x20L 4
45 0612045 Screw M5x40L 1
46 0612046 Flat washer φ12.5xφ20x1.5t 1
47 0612047 F0lan
g
e nut M10 2
48 0612048 Bearin
g
assembl
y
1
49 0612049
A
djustment bolt 2 2
50 0612050 Sensor bracket 1
51 0612051 Left chain cover 1
52 0612052 Flat washer φ4.3xφ12 2
53 0612053 Hand pulse sensor 2
54 0612054
A
llen ke
y
1
55 0612055 Box wrench 1
