OPERATION OF YOUR FITNESS BIKE
GETTING FAMILIAR WITH THE CONTROL PANEL
UB120 CONSOLE
Key Functions
MODE: Press to select functions. Press the button and hold for two seconds to reset all
functions to zero, except ODOMETER.
Functions
Scan: Press MODE button until “▼” appears at SCAN position, the console displays: time, speed, distance,
calories, odometer and pulse, in sequence for 6 seconds at a time.
Time: Display the time from exercise start to the end
Speed: Display the current speed.
Distance: Display the distance from exercise start to the end.
Calories: Display the calories burned from the exercise start to the end.
The calorie readout is an estimate for an average user. It should be used only as comparison
between workouts on this unit.
ODO: Display the total accumulated distance you have travelled. The odometer does not reset unless you
remove the batteries.
Pulse: Display an average current heartbeat rate in beats per minute (BPM). To use this feature, place hands
on the pulse grips and hold for 6 ~ 7 seconds to get a more accurate reading. Please note that due to
contact delay, the heart rate will be higher than the actual heart rate during the first 2 ~ 3 seconds of
measurement, then will return to normal level. The measurement value shouldn’t be regarded as the
basis of medical treatment.
Getting Familiar with the Control Panel
FUNCTION
AUTO SCAN Every 6 seconds
TIME 0:00’~99:59’
SPEED 0.0~999.9 KM/H（MILE/H）
DISTANCE 0.00~999.9 KM（MILE）
CALORIES 0.0~999.9 CAL
ODOMETER 0.0~9999 KM（MILE）
PULSE 40~240 BPM
BATTERY TYPE 2 AAA or UM 4
OPERATING TEMPERATURE 0°C ~ +40°C, 32˚F ~ 104˚F
STORAGE TEMPERATURE -10°C ~ +60°C, 14˚F ~ 140˚F
(1) The console turns on when you start pedaling or when you press a key.
(2)
The console turns off automatically after 4 minutes of inactivity.
