6.
Use the screw to the set the tightness of the timing belt on the middle plate.
Note: The longest screw is used to set the tightness of the timing belt. Do not fully tighten it.
Otherwise, the timing belt may be damaged.
7. Install the optical shaft components.
(1) Drag the middle plate to make it close to the rear plate.
