VESDA-EVES-A10-P Product Guide
6 www.xtralis.com
If the measured smoke level in a sector is higher than the user-set alarm thresholds then an Alert, Action, Fire
1 or Fire 2 alarm condition is reported for that sector, depending on the smoke level. Also, the first sector to
pass the alert level is reported as the first alarm sector (FAS).
Air is exhausted from the VES-A10-P and may be vented back into the protected zone.
Alarms can be signalled via Relays and VESDAnet. Ethernet and WiFi can be used for configuration and
secondary monitoring, and a USB interface is provided for initial setup.
The detector has a LED plus LCD user interface. A series of LEDs display Alarm, Fault, Disable and detector
power on status. The detector has a buzzer which can be configured to signal alarm, fault, disable and
standby status. A button allows the user to Reset or Disable the detector or to acknowledge status. In
addition an LCD displays detector status including smoke level and a smoke level bar graph per sector, alarm
thresholds per sector, trouble status, % airflow level, normalization status and filter life used.
2.3 Front Panel
The VES-A10-P detector provides the following information and control capability:
l Status LEDs: Alert, Action, Fire 1, Fire 2, Disabled, Fault and Power.
l Controls: Reset and Disable button. Touch-screen featuring a limited set of additional controls and
lookup tools.
2.3.1 Status LEDS
The VESDA-E VES-A10-P detector features a range of LED Indicators which illuminate when their respective
activation conditions are met.
LED Symbol Description
Fire 2 The Fire 2 LED is lit when the Fire 2 Alarm threshold is
reached. (The LED will flash once per second until the
condition is acknowledged.)
Fire 1 The Fire 1 LED is lit when the Fire 1 Alarm threshold is
reached. (The LED will flash once per second until the
condition is acknowledged.)
Action The Action LED is lit when the Action threshold is reached.
(The LED will flash once per second until the condition is
acknowledged.)
Alert The Alert LED is lit when the Alert threshold is reached. (The
LED will flash once per second until the condition is
acknowledged.)
Disabled The DISABLED LED is lit continuously when the detector is
disabled and flashes once every two seconds when the
detector is in Standby mode.
Fault The FAULT LED is lit when a fault condition is detected. The
LED will flash once per second until the condition is
acknowledged.
Refer to Chapter 8 for information on troubleshooting.
Power The POWERLED illuminates when the detector is powered
up.
Table2-1: LED Indicators
Notes:
l The LEDs are tested during the power up cycle. To manually test the LEDs, run the Lamp Test using
Xtralis VSC.
