VESDA-EVES-A10-P Product Guide
www.xtralis.com 11
2.7 Specifications
Specification Value
Supply Voltage 18 to 30 VDC (24 VDC Nominal)
Power Consumption @24 VDC
Power (Quiescent) 10.5 W
Setting 1
Setting 5 Setting 10
Power (In Alarm)
10.8 W
8.6 W
9.4 W
15.4 W
15.2 W
Aspirator
Peak current: 1.5A
Dimensions (WHD) 350 mm x 225 mm x 135 mm
(13.8 in x 8.9 in x 5.3 in)
Weight 4.4 kg (9.7 lb)
Operating Conditions
Please consult your Xtralis representative for
information on operation outside these parameters
or where sampled air is continually above 0.05%
obs/m (0.015% obs/ft) under normal operating
conditions.
l Ambient: 0°C to 39°C (32°F to 102°F) *
l Tested to (EN54-20): -10°C to 55°C (14°F to 131°F)
l Sampled Air: -20°C to 60°C (-4°F to 140°F) **
l Humidity: 5% to 95% RH, non-condensing
* Product UL listed for use from 0°C to 38°C (32°F to 100°F)
** Sampled Air temperature shall reach Ambient Detector
temperature upon entry into Detector. Refer to Xtralis Design
Guides & Application Notes for sampled air pre-conditioning.
Storage Conditions
(Non-operational)
l Humidity: Dry (<95%)
l Temperature: 0° to 85°C
l Must not be exposed to sunlight or other radiation sources
Sampling Pipe Network l Maximum length per pipe when using four straight
pipes:
l Four pipe VES-A10-P:70 m (230 ft)
l Maximum total pipe length (with branches):
l Four pipe VES-A10-P: 560 m (1,837 ft)
l Pipe Modeling Design Tool:ASPIRE
l Minimum airflow per pipe: 15 l/m
Note: Standards compliance of a particular pipe network
must be determined using ASPIRE.
Inlet Pipe Size l External Diameter: 25 mm or 1.05 in (3/4" IPS)
Exhaust Pipe Size l External Diameter: 25 mm or 1.05 in (3/4" IPS) via
adaptor
Relays l 12 programmable relays
l Contacts rated 2A @ 30 VDC (Resistive)
l Programmable to latch or not latch alarm or fault states
IP Rating IP 40
(not UL tested)
Mounting Upright or inverted
Cable Access 4 x 26 mm (1 in) ports
Cable Termination Screw terminal blocks (0.2-2.5 sq mm, 24-14 AWG)
Interfaces l USB (Type 2)
l Ethernet (RJ45)
l WiFi, 802.11 b/g/n
Dynamic Range 0.0002%/m to 32%/m (10%/ft to 0.00006%/ft)
Table2-2: VES-A10-P Detector Specifications
