Specification Value
IP Rating IP30
Cable Access 8 x 25 mm (1in) knockouts in various positions
Cable Termination Screw terminal blocks (0.2-2.5 sq mm, 30-12 AWG)
Sensitivity Range 0.005 to 20% obs/m (0.0015 to 6.25% obs/ft.)
Threshold Setting Range l Alert: 0.005 - 1.990% obs/m
(0.0016 - 0.6218% obs/ft.)
l Action: 0.010 - 1.995% obs/m
(0.0031 - 0.6234% obs/ft.)
l Fire 1: 0.015 - 2% obs/m
(0.0046 - 0.625% obs/ft.)
l Fire 2: 0.020 - 20% obs/m
(0.0063 - 6.25% obs/ft.)**
** Limited to 12% obs/m 4% obs/ft. in UL mode
All shipments are factory configured for UL Mode. If the UL Mode is
switched OFF the UL listing will be voided.
Table 3-1: Product Specifications (continued...)
3.1.1 Key Software Features
Event log
Up to 18,000 events stored on FIFO basis
AutoLearn
Minimum: 15 minutes
Maximum: 15 days, 23hrs, 59 minutes
Recommended minimum period: 1 day
During AutoLearn, thresholds (i.e. alarm thresholds) are NOT changed
from pre-set values
Referencing Compensation for external ambient conditions
Four Alarm Levels Alert, Action, Fire 1 and Fire 2
Two Fault Warning Levels Minor Fault and Urgent fault
Software Programmable relays 7 or 12
Maintenance Aids
Filter and flow monitoring
Event reporting via VESDAnet or event log
Auto Scan and Threshold Settings Detector selects the appropriate scan threshold automatically
