Xtralis VESDA VLS User Manual

VSC Software Overview
5-10 VESDA Student Workbook
Main Toolbar
Button
Tooltip
Description
New
Creates a new configuration file.
Open
Displays the Open dialog where you can specify the existing configuration file
you want to open.
Save
Saves the current configuration file to disk. If it is a new configuration, the
Save As dialog is displayed where you can specify a name and location for
the new file.
Merge Configurations
Displays the
Merge Configuration dialog where you can compare the
configuration of two devices and decide which is the correct value to use.
Main Toolbar
Button
Tooltip
Description
Device Browser
Displays the
Device View for the selected device.
Event Log
Displays the
Event Log View for the selected device.
Active Event List
Displays the
Active Event List View for the selected device.
Device Status
Displays the
Status View for the selected device.
Graph
Displays the
Trend Graph View for the selected device.
