20 SUBMENU STATUS
Status of all units within a pump group
Using this submenu it is possible to check the status (including failures and motor hours) of
all connected units.
21
21 STATUS UNITs
00000000
Status of all units
This parameter gives a quick overview about the status of the connected units
- In Cascade serial/synchron mode the status of all (max. 8) connected units is shown
(whereas 1=activated / 0=deactivated)
- In Cascade relay mode (MASTER is equipped with additional Relay Card) the status
of the 5 Relay- switching contacts is shown.
E.g. Mode – Cascade serial/synchron
21 STATUS UNITs
11001000
Unit 1, 2 and 5 are running
E.g. Mode – Cascade relay
21 STATUS UNITs
10100 - - -
Relay Contact 1 and 3 are closed
22
22 SELECT DEVICE
* 1 *
Select device
Possible settings: 1-8
Check the current status, the motor hours and the last failures which occurred.
The selection is depending on the selected mode [105].
Select desired unit by pressing
▲ or ▼.
Mode CASCADE SERIAL/SYNCHRON:
The selection specifies the address of the HYDROVAR units
E.g. Device 1 -> MASTER Inverter with pre-selected address 1
Device 2 -> BASIC Inverter with pre-selected address 2
Device 3 -> BASIC Inverter with pre-selected address 3
For set the address on a BASIC Inverter, see chapter addressing.
To set the address on a MASTER Inverter, see parameter [106] or submenu [1200] RS485-
Interface.
