Yaber K2s User Manual

EN 6
Installation
1. Install the TV Dongle
Lid
Tray
TV Dongle
Slot
1. Push once to open the lid, and take out the tray.
2. Mount the TV Dongle and make sure the Micro HDMI port downside and the Micro USB port
upside.
3. Insert the mounted TV Dongle into the slot.
4. Plug the USB power cable into the Micro USB port, and push to close the lid.
Micro USB port
(Mark on the Back)
Micro HDMI port
(Mark on the Back)
USB Power
Cable
Mounted TV
Dongle

Yaber K2s Specifications

General

Wireless Connectivity	Yes
Bluetooth	Yes
Zoom	50% - 100%
Throw Ratio	1.5:1
Resolution	1920 x 1080
Keystone Correction	±50° Vertical & Horizontal
Speaker	10W
Throw Distance	1.5m - 6m
Aspect Ratio	16:9, 4:3
Ports	HDMI, USB, AV, Audio out
Dimensions	26 x 23 x 11 cm
Operating System	None (No built-in OS)
